**Folding Carton Box — Technical Dieline Description** A flat, unfolded folding-carton packaging dieline with nominal assembled dimensions of 170 × 140 × 165 mm. The carton consists of four connected rectangular body panels arranged horizontally in alternating widths of 170 mm and 140 mm, each with a height of 165 mm. A narrow, angled side-gluing flap is attached to the far-left edge. The upper structure includes a large top flap with rounded upper corners above the first panel, plus two additional top flaps with slightly angled sides above the second and fourth panels. The lower structure features four differently shaped folding flaps, including tapered flaps with angled shoulders and rectangular end sections, as well as a central flap with a stepped notch. All cutting and folding outlines are represented by fine black lines on a plain white background. The dieline is presented as a clean, flat, two-dimensional technical drawing with no perspective, shading, printed graphics, or decorative elements. Dimension guides indicate the main panel widths, body height, and the specified carton dimensions in millimetres.
